Flow Sensors for Industrial Process Monitoring

Flow sensors are used to measure the flow rate of liquids or gases within industrial processes. Different measurement technologies are applied depending on medium properties, flow range, accuracy requirements, and installation conditions.
Flow measurement is essential for process control, energy management, and system efficiency in automation systems, machinery, and HVAC applications. Selecting the appropriate flow sensor requires careful consideration of pipe size, medium characteristics, pressure loss, and operating environment.

ProductMeasurement PrincipleAccuracy LevelDisplayHousingCommunication
PLSX Thermal Flow SensorThermal (Calorimetric)LowLED StatusPlastic / Stainless Steel (Optional)Switching Output
PLSU Thermal Flow SensorThermal (Calorimetric)LowLED StatusStainless SteelSwitching Output
PLSN Thermal Flow SensorThermalLowDigital LEDStainless Steel (Rotatable)Switching Output
GF-AM1 Electromagnetic Flow SensorElectromagneticHigh (±0.5% RS)LCD (Optional)Aluminum + PEEK Liner4–20mA / Pulse / RS485 Modbus
GF-KS Clamp-on Ultrasonic SensorUltrasonic (Clamp-on)High (±1.0%)NoPlastic HousingAnalog / Digital Output
GF-KG Clamp-on Ultrasonic SensorUltrasonic (Clamp-on)HighNoPlastic HousingAnalog / Digital Output
GF-X5 Clamp-on Ultrasonic SensorUltrasonic (Clamp-on)Medium (±1.5%)IPS LCDIndustrial HousingAnalog / Digital Output
FMV IO-Link Vortex Flow SensorVortex (Von Karman)MediumIPS DisplayIndustrial Metal HousingIO-Link / Switching Output
Show sidebar
gf-x5-clamp-on-ultrasonic-flow-sensor

GF-X5 Clamp-on Ultrasonic Flow Sensor

±1.5% high accuracy
Non-invasive, hygienic measurement
No clogging, low pressure loss
4-line IPS LCD display
Flow and temperature bar graph
Button-based menu operation

plsn-thermal-flow-sensor

PLSN Thermal Flow Sensor

Calorimetric detection principle Flow and temperature alarm function Digital LED display with mirroring Programmable via 3 buttons 360° rotatable housing M18 × 1.5 internal thread PNP normally open output M12 electrical connector

plsu-thermal-flow-sensor

PLSU Thermal Flow Sensor

Thermal conductivity detection principle Insertion-type flow measurement LED flow status indicator Adjustable switching point Full stainless steel housing Multiple process connection sizes Suitable for water and oil monitoring

plsx-thermal-flow-sensor

PLSX Thermal Flow Sensor

Thermal conductivity detection principle LED flow status indication Adjustable switching point Plastic or stainless steel housing Multiple process connections Suitable for liquid and gas monitoring

fmv io-link vortex flow sensor

FMV-100 IO-Link Vortex Flow Sensor

Flow,Temperature dual switches Range: 10-100L/min NPN/PNP/push-pull optional High-resolution lPS display Cumulative flow recording function Various thread & model selections Simple button menu operation Four viewing directions

fmv io-link vortex flow sensor

FMV-040 IO-Link Vortex Flow Sensor

Flow,Temperature dual switches Range: 5-40L/min NPN/PNP/push-pull optional High-resolution lPS display Cumulative flow recording function Various thread & model selections Simple button menu operation Four viewing directions

XGZF-4000 Air Flow Sensor

MEMS thermal mass flow technology Flow range: 5 to 500 SLM Analog or digital output Unidirectional or bidirectional flow Fast response and high sensitivity Stable and reliable performance

XGZF-3000 Air Flow Sensor

MEMS thermal mass flow technology Flow range: 100 to 3000 SCCM Analog or digital output Uni- or bidirectional measurement Fast response and high sensitivity Stable and reliable performance

fmv io-link vortex flow sensor

FMV-016 IO-Link Vortex Flow Sensor

Flow,Temperature dual switches Range: 2-16L/min NPN/PNP/push-pull optional High-resolution lPS display Cumulative flow recording function Various thread & model selections Simple button menu operation Four viewing directions

gf-am1-electromagnetic-flow-sensor

GF-AM1 Electromagnetic Flow Sensor

Flow range: 3 L/h to 40 m³/h Velocity range: 0.01–10 m/s Accuracy: ±0.5% RS Repeatability: 1/3 of accuracy Media conductivity ≥20 µS/cm Working pressure: up to 1.6 MPa Max temperature: 70 °C Protection class: IP65

gf-ks-clamp-on-flow-sensor

GF-KS Clamp-on Ultrasonic Flow Sensor

Clamp-on, non-invasive installation ±1.0% measurement accuracy Integrated signal processing Bubble and particle detection Bi-directional flow measurement No pressure loss or blockage

gf-kg-clamp-on-ultrasonic-flow-sensor

GF-KG Clamp-on Ultrasonic Flow Sensor

High precision & stability
Non-contact measurement
Bi-directional, volume & bubble detection
Embedded circuitry, no external system
No blockage, low pressure loss
Standard outputs for integration
