XGZP-6810D Pressure Sensor
±500Pa/±125Pa
3.0V～5.5V Power Supply
Differential Pressure Type
Air or Nitrogen, Oxygen(non-condensing)
I2C Interface
Temp. Compensated: 0℃～50℃
Affordable Cost, Easy-to-use
The XGZP6810D pressure sensor is CFSensor’s series of differential pressure sensors designed for high-volume applications with an affordable cost and perfect performance. The pressure is measured by a thermal sensor element using flow-through technology. The XGZP6810D provide ±500 Pa and ±125 Pa pressure range for measuring air and non-aggressive gases with high accuracy and extremely low offset drift.
XGZP6810D is a prefect silicon pressure sensor offering a ratiometric digital data(I2C interface) for reading differential pressure over the specified full scale pressure span.
The XGZP6810D is fully calibrated and temperature compensated for specified span, so XGZP6899D pressure sensor satisfy the perfect accuracy, which is designed for a wide range of application in medical care&health, home appliances, industry, air flow measurement, loT and other pneumatic devices/meters etc by utilizing a microcontroller or microprocessor with I2C interface.
