XGZP-6812D Pressure Sensor
0～100kPa…2500kPa
1.8V～3.3V Power Supply
Absolute Pressure Type
For Non-corrosive Gas or Air
Calibrated Digital Signal(I2C Interface)
Temp. Compensated
Temperature Accuracy:±1°C
XGZP6812D is a perfect silicon pressure sensor offering a ratiometric I2C interface for reading pressure over the specified full scale pressure span.
The XGZP6812D incorporates a silicon piezoresistive pressure sensor die and an interior Application Specific Integrated Circuit(ASIC) in a small COB package.
The XGZP6812D is fully calibrated and temperature compensated for offset, sensitivity, temperature and non-linearity, so XGZP6812D pressure sensor satisfy the prefect repeatability, linearity, stability and sensibility, which can be applied directly in home appliances, consumer electronic, industry, automotive and other pneumatic devices etc.
XGZP6812D pressure sensor is for high volume application at an affordable cost but perfect performance.
