XGZP-6818D Pressure Sensor
0kPa～100kPa…2500kPa
3.3V～5.5V Power Supply
Absolute Pressure Type
For Non-corrosive Gas or Air
Calibrated Digital Signal
Multiple Working Methods
High Resolution
Temperature Accuracy: ±1°C
XGZP6818D is a perfect silicon pressure sensor offering a ratiometric I2C interface for reading pressure over the specified full scale pressure span.
The XGZP6818D incorporates a silicon piezoresistive pressure sensor die and an interior Application Specific Integrated Circuit(ASIC) in a small COB package.
The XGZP6818D is fully calibrated and temperature compensated for offset, sensitivity, temperature and non-linearity, so XGZP6818D pressure sensor satisfy the prefect repeatability, linearity, stability and sensibility, which can be applied directly in medical care&health, home appliances, consumer electronic, industry, automotive and other pneumatic devices etc.
XGZP6818D pressure sensor is for high volume application at an affordable cost but perfect performance.
