XGZP-6858D Pressure Sensor
0kPa～100kPa…700kPa
2.5V～5.5V Power Supply
Absolute Pressure Type
For Non-corrosive Gas or Air or Liquid
Calibrated Digital Signal(I2C Interface)
Temp. Compensated: 0℃～60℃
Temperature Measurable
XGZP6858D is a prefect silicon pressure sensor offering a ratiometric digital data(I2C interface) for reading differential pressure over the specified full scale pressure span. The XGZP6858D incorporates a silicon piezoresistive pressure sensor chip and an interior signalconditional Application Specific Integrated Circuit(ASIC) in a SOP8 package, which can be mounted directly on a standard PCB by SMT. The covering gel overlying the die can make sensor available to measure the the water media or non-corrosive liquid.
The XGZP6858D is fully calibrated and temperature compensated for specified span, so XGZP6858D pressure sensor satisfy the perfect accuracy, which is designed for a wide range of application in medical care&health, home appliances, consumer electronic, industry, automotive, loT and other pneumatic devices etc by utilizing a microcontroller or microprocessor with I2C interface.
XGZP6858D pressure sensor is for high volume application at an affordable cost and perfect performance.
