XGZP-6877D Pressure Sensor
-100kPa…0kPa…1000kPa
2.5V～5.5V Power Supply
Pressure Type(Positive&Vacuum)
For Non-corrosive Gas or Air
Calibrated Digital Signal(I2C Interface)
Temp. Compensated: 0℃～+60℃
Temperature Measurable
XGZP6877D is a prefect silicon pressure sensor offering a ratiometric digital data(I2C interface) for reading differential pressure over the specified full scale pressure span. The XGZP6877D incorporates a silicon piezoresistive pressure sensor chip and an interior signalconditional Application Specific Integrated Circuit(ASIC) in a SOP6 package, which can be mounted directly on a standard PCB by SMT.
The XGZP6877D is fully calibrated and temperature compensated for specified span, so XGZP6877D pressure sensor satisfy the perfect accuracy, which is designed for a wide range of application in medical care&health, home appliances, consumer electronic, industry, automotive, loT and other pneumatic devices etc by utilizing a microcontroller or microprocessor with I2C interface.
XGZP6877D pressure sensor is for high volume application at an affordable cost and perfect performance.
