XGZP-6847D Pressure Sensor
-100kPa…0kPa…1500kPa
2.5V～5.5V Power Supply
Pressure Type(Positive&Vacuum)
For Non-corrosive Gas or Air
Digital Signal(I2C Interface)
Temp. Compensated: 0℃～60℃
Temperature Measurable
Affordable Cost, Easy-to-use
XGZP6847D is a perfect silicon pressure sensor offering a ratiometric I2C interface for reading pressure over the specified full scale pressure span. The XGZP6847D incorporates a silicon piezoresistive pressure sensor(XGZP SOP6) and an on-board Application Specific Integrated Circuit(ASIC) under PC board in a DIP6 package.
The XGZP6847D is fully calibrated and temperature compensated for specified span, so XGZP6847D pressure sensor satisfy the perfect accuracy, which is designed for a wide range of application in medical care&health, home appliances, consumer electronic, industry, automotive, loT and other pneumatic devices etc by utilizing a microcontroller or microprocessor with I2C interface.
XGZP6847D pressure sensor is for high volume application at an affordable cost and perfect performance.
