gp-2211-flush-diaphragm-pressure-sensor

GP-2211 Flush Diaphragm Pressure Sensor

Measuring range up to 35 MPa Food-grade oil-filled isolation 316L stainless steel housing Flat diaphragm overload protection G1/4 thread with flush membrane

gp-2301-hygienic-pressure-sensor

GP-2301 Hygienic Pressure Sensor

Flush diaphragm for hygienic processes 1.4435 stainless steel, polished surface DIN 11851 hygienic process connection AK100 safety silicone oil filling Temperature-compensated MEMS chip Laser-trimmed signal correction

gp-402-i2c-digital-pressure-sensor

GP-402 I2C Digital Pressure Sensor

24-bit high-resolution ADC I²C digital pressure and temperature output Pressure range from -100 kPa to 3.5 MPa Low power consumption Compact 316L SS wetted parts Diaphragm protection

gp-2710-intellgent-pressure-sensor

GP-2710 Intelligent Pressure Sensor

Built-in MCU for intelligent processing Flexible configuration RS485, I2C, and SPI interfaces Programmable via Modbus over RS485 Accuracy up to ±0.03% FS (TEB) Integrated high-precision temperature sensor Supports low-power operation for embedded systems

gp-1100-atmosphere-pressure-sensor

GP-1100 Atmosphere Pressure Sensor

MEMS silicon resonant pressure sensor
Accuracy up to ±0.01% FS
Frequency signal output
Operating temperature -40°C to 80°C
High long-term stability
Flexible electrical and pressure interfaces

GP-1900 To-8 Pressure Sensor

GP-1900 To-8 Pressure Sensor

Range from 20 kPa to 1 MPa
Gauge, absolute and differential types
Constant current power supply
Temperature compensation
TO-8 package for PCB mounting
For non-corrosive gases and liquids

GP-2000 Pressure Sensor

GP-2000 Pressure Sensor

Range from 0.35 MPa to 70 MPa
Isolated oil-filled sensing structure
316L stainless steel housing
Compact size φ12.6 mm
Temperature compensated
High overload resistance

GP-2080 Pressure Sensor

GP-2080 Pressure Sensor

Measuring range up to 35 MPa Laser temperature compensation Standard Ø19 mm compact size High accuracy and long-term stability Multiple housing material options

GP-2900 Differential Pressure Sensor

GP-2900 Differential Pressure Sensor

Wide range: 0 kPa to 3.5 MPa Static pressure up to 20 MPa Temperature compensated output Stainless steel diaphragm isolation High accuracy and long-term stability Robust 316L stainless steel housing

GP-2210 Flush Diaphragm Pressure Sensor

GP-2210 Flush Diaphragm Pressure Sensor

Measuring range up to 60 MPa Temperature compensation (0–70 °C) 316L stainless steel housing Diaphragm overload protection Pure flat diaphragm design

GP-6210 High Accuracy Pressure Transmitter

GP-6210 High Accuracy Pressure Transmitter

High accuracy: up to ±0.03% FS 3.3ppm high resolution RS485 & 4~20mA double outputs Temperature output support Software zero clear and recalibration Stainless steel, robust design

GP-6400 Pressure Transmitter

GP-6400 Pressure Transmitter

Range -1 bar … 0~0.1 bar up to 1500 bar Gauge, absolute or sealed gauge 4~20 mA two-wire or 0/1~5/10 V three-wire Resistant to ice blockage, shock and water hammer Welded sensor, Hastelloy option IP65 connector type / IP68 cable type

Industrial Grade Pressure Sensors

Industrial grade pressure sensors are designed for demanding operating conditions in industrial environments. They are used in applications involving high pressure, temperature variation, vibration, corrosive media, and long-term continuous operation.

Different sensing principles such as piezoresistive, thin-film, strain gauge, and capacitive technologies are applied depending on the measurement task. Rather than pursuing a single “best” solution, industrial pressure sensor selection focuses on reliability, environmental compatibility, and long-term stability under real operating conditions.

oil-filled pressure sensor
